เครื่องบรรจุน้ำแข็งอัตโนมัติ

/ CBFI เครื่องบรรจุน้ำแข็งอัตโนมัติ

CBFI เครื่องบรรจุน้ำแข็งอัตโนมัติ

  • หมายเลขสินค้า:

    API Specs

สินค้าใหม่

  • รายละเอียดสินค้า
  • วิดีโอ

CBFI AIP รายละเอียดเครื่องบรรจุน้ำแข็งอัตโนมัติ

automatic ice packaging machine


CBFI เครื่องบรรจุน้ำแข็งอัตโนมัติบรรจุได้รวดเร็วประหยัดเวลาและกำลังคนส่วนใหญ่ใช้ในการบรรจุน้ำแข็งหลอดและก้อน น้ำแข็ง เป็นตัวเลือกแรกสำหรับน้ำแข็งที่กินได้ขนาดกลางและขนาดใหญ่ โรงงาน.

เชื่อมต่อฟังก์ชั่นการจัดส่งการชั่งการบรรจุการปิดผนึกการนับ ฯลฯ


  • pe บรรจุภัณฑ์ - เครื่องบรรจุภัณฑ์ที่ใช้บรรจุภัณฑ์ถุง PE ช่วยประหยัดค่าถุงบรรจุภัณฑ์สามารถทำม้วนฟิล์มได้ เป็น พ.ศ. 2543 ถุง
  • เครื่องบรรจุอัตโนมัติทำถุง
  • ความเร็วสูง กับ มั่นคง ปิดผนึก. มันขึ้นอยู่กับ 25bags / นาที
  • ไม่มีขั้นตอน การปรับ - ความเร็วในการบรรจุคือ stepless ปรับแค่ปรับความเร็วในการตัด กับ ลูกบิดความเร็วในการบรรจุจะเปลี่ยนโดยอัตโนมัติ ตามนั้น
  • เดอะ การเปลี่ยนฟิล์มทำได้สะดวก - เครื่องบรรจุภัณฑ์สะดวกในการเปลี่ยนฟิล์มดึงฟิล์มไปที่ทางเข้าของฟิล์มกดปุ่มฟิล์มจะถูกติดตั้งโดยอัตโนมัติ
  • ค่าใช้จ่ายในการลงทุนอุปกรณ์สามารถกู้คืนได้ในเวลาน้อยกว่า ในปี
  • กระบวนการบรรจุถูกสุขลักษณะตามมาตรฐานสุขาภิบาลอาหาร
  • โรงน้ำแข็งอัตโนมัติเพื่อประเมินประสิทธิภาพและ สุขาภิบาล.



พารามิเตอร์ผลิตภัณฑ์



เครื่องบรรจุน้ำแข็งอัตโนมัติรุ่น AIP-100 พารามิเตอร์
ความจุ
10 ~ 25bags / นาที
น้ำหนักน้ำแข็ง 2 ~ 18kgs / กระเป๋า
วัสดุฟิล์ม
LLDPE

ความหนาของฟิล์ม

2 ~ 5kgs: 0.04 มม. ขั้นต่ำ

5 ~ 15kgs: 0.06 มม. ขั้นต่ำ

ขนาดกระเป๋า

ความยาว: 400 ~ 800 มม.

ความกว้าง: 300 ~ 380 มม.

แหล่งจ่ายไฟ380V-3P-50Hz, 4.37kW
ความกดอากาศ ≥0.6MPa
น้ำหนักเครื่อง 800kgs
เครื่อง ขนาด (L * W * H) 3350 มม. * 1170 มม. * 2250 มม.


รายละเอียดสินค้า

PLC ควบคุม

ด้วย ตัวควบคุมระบบเครื่องสามารถปรับเปลี่ยนได้อย่างง่ายดายสำหรับพารามิเตอร์ต่างๆตาม ต่อ ความต้องการ


นักกีฬายกของ: ถ่ายทอดน้ำแข็งโดยอัตโนมัติ

เครื่องชั่ง: น้ำหนักเปลี่ยนแปลงได้ง่าย ไม่มี ใช้มาตราส่วน

พี lastice ภาพยนตร์: ทำกระเป๋าโดยอัตโนมัติ




ฝากข้อความ

ถ้า คุณ มีความสนใจในผลิตภัณฑ์ของเราและต้องการทราบรายละเอียดเพิ่มเติมโปรดฝากข้อความไว้ที่นี่เราจะตอบกลับ คุณ โดยเร็วที่สุด ทำได้.
